Description
OVERVIEW
- Torque Range: 0.8-12 NM
- Torque Accuracy: Meets ISO 5393 Cmk> 1.67 at +/- 10% tolerance
- Li-ion Battery Technology
- Unique patented torque control shut-off system adjustable for different applications & joint types
- Precision alloy steel gearing for high durability
- LED light for area illumination
- Durable brushless motor promotes longer life and lower maintenance
- Variable speed control setting capability via Programmer
- Non-Contact switch provides longer mechanical life
- Ergonomic design for user comfort and less fatigue
- LED indicators for tightening OK, not OK, Reverse Operation and Battery Indicator
MODELS & SPECIFICATIONS
| Model | Free Speed (rpm) | Drive Output (in.) | Torque Range** | Weight (lb) | Battery Type | |||
| SHUT OFF | NM | FT/LB | Type | V | Ah | |||
| SC180BBS3 | 500-1550 | 1/4* | 0.8-3 | 7-27 | 2.1 | Li-ion | 18 | 2 |
| SC180BBS6 | 300-900 | 1/4* | 1-6 | 9-53 | 2.1 | Li-ion | 18 | 2 |
| SC180BBS9 | 300-700 | 1/4* | 1.5-9 | 13-80 | 2.1 | Li-ion | 18 | 2 |
| SC180BBS12 | 250-550 | 1/4* | 2-12 | 18-106 | 2.1 | Li-ion | 18 | 2 |
| *…Female hexagon drive Quick Change Chuck?? | ||||||||
| **…To be used as a guide only as final torque depends on the following factors: type of joint; accessories.?? | ||||||||
| ***…For Optimum battery life maximum of 6 bolts per minute is recommended.?? | ||||||||
