OVERVIEW
- Shut-off TDBS Series
- Torque Range: 0.3-10 NM, 2.65-88.50 LBF.IN
- Precision toque control clutch for high accuracy and prolonged durability
- One hand Reverse for right and left hand operators
- Gravity casting housing for high durability
- Rubberized non-slip grips offer operator confidence and precision with excellent thermal ergonomics
MODELS & SPECIFICATIONS
| Model | Free Speed (rpm) | Drive Output (in.) | Torque Range | Weight (lb) | Length (mm) | Air Inlet (in.) | Hose Size (in.) | |
| NM | in-lb | |||||||
| TDBS-10R16 | 1600 | 1/4* | 0.3-1.5 | 2.7-13.2 | 1.94 | 298 | 1/4 | 1/4 |
| TDBS-10R09 | 900 | 1/4* | 0.3-1.8 | 2.7-15.9 | 1.94 | 298 | 1/4 | 1/4 |
| TDBS-20R17 | 1700 | 1/4* | 1-3.5 | 8.8-31 | 2.25 | 314 | 1/4 | 1/4 |
| TDBS-20R11 | 1100 | 1/4* | 1-4 | 8.8-35.4 | 2.25 | 314 | 1/4 | 1/4 |
| TDBS-20R07 | 700 | 1/4* | 1-4.5 | 8.8-39.8 | 2.25 | 314 | 1/4 | 1/4 |
| TDBS-30R11 | 1100 | 1/4* | 3.5-6 | 31-53 | 3 | 350 | 1/4 | 1/4 |
| TDBS-30R07 | 700 | 1/4* | 3.5-8 | 31-70 | 3 | 350 | 1/4 | 1/4 |
| TDBS-30R05 | 500 | 1/4* | 3.5-10 | 31-88 | 3 | 350 | 1/4 | 1/4 |
| *…Female hexagon drive Quick Change Chuck?? | ||||||||
| ***…Tools are designed for a working pressure of 6.3 bar 90 PSI?? | ||||||||
